Fiber Optic Solutions

Fusion Splicers & Accessories


TYPE-72C

High Definition Core Aligning fusion splicer Advanced, Adept, Assured



Compact, Lightweight & Faster

  • 2.2kg with battery for 300 splice & heat cycles

  • Faster 5s splice in SM Quick Mode

  • Reduced 9s heat shrink time

Dual ovens with flexible clamps



Independent

  • Fast-heating 9s

  • Productive

  • Programmable

  • User selectable clamp operation



High Environmental Durability

  • IPx2 water resistance

  • IP5x dust resistance

  • Splice at 50°C

  • Work at 6000m

  • 76cm drop on 5 faces



Brand-new touch panel and UI



Wide and high-resolution touch panel -5" touch screen color LCD display

Smartphone-like easy operation



Wireless LAN connectivity to SumiCloud™

  • The world-first fusion splicer with Wireless LAN Connectivity

  • SumiCloud™ smartphone App. to support splicing job

  • WLSD card brings SumiCloud™ services to your splicer via our smartphone App.


T-57

Automatic Adaptive Core fusion splicer Fast, Capable, Practical



Compact, Lightweight & Faster​

  • 2.0kg with battery for 300 splice & heat cycles

  • Faster 6s splice in SM Quick Mode

  • Reduced 15s heat shrink time



Brand-new touch panel and UI



  • Wide and high-resolution touch panel

-5" touch screen color LCD display

  • Smartphone-like easy operation

Improved EnvironmentaVl Durability

  • IPx2 water protection

  • IP5x dust protection

  • Splice at 50°C

  • Work at 6000m

  • 76cm drop on 5 faces



High Speed Oven



  • Fast-heating 15s

  • Productive

  • Programmable

1

T-400S

Active Clad Alignment fusion splicer

Fast, Versatile, Easy

Carry out your mission as fast as possible

  • Fast Splicing 6sec / Heating 24sec



All the FTTx fibre splices in one machine

  • Applicable to various fiber & cable types



Simple operation by brand-new user interface



Fully redesigned for improved user experience


TYPE-201e-VS

Handheld fusion splicer
Lightweight, Tough, Handy

  • Fastest, smallest and lightest

  • Fully navigational touchscreen and intuitive GUI for user friendliness

  • Improved environmental durability includes shock, water and dust resistance and windproof features (including splicing drop cables at a wind velocity of 15 m/s)

  • Approx.100 splice & heat cycles with BU-12L

  • Built-in help videos play on the splicer display

Software updates and remote diagnosis services via Internet


TYPE-201e-M4

Handheld fusion splicer
Lightweight, Tough, Handy

  • Fastest, smallest and lightest

  • Fully navigational touchscreen and intuitive GUI for user friendliness

  • Improved environmental durability includes shock, water and dust resistance and windproof features (including splicing drop cables at a wind velocity of 15 m/s)

  • Approx.100 splice & heat cycles with BU-12L

  • Built-in help videos play on the splicer display

Software updates and remote diagnosis services via Internet

TYPE-72M12

Compact, Lightweight & Faster

  • 2.1kg with battery for 180 splice & heat cycles

  • Faster 11s splice in SM Quick Mode

  • Reduced 35s heat shrink time



Dual ovens with flexible clamps

  • Independent

  • Fast-heating 35s

  • Productive

  • Programmable

  • User selectable clamp operation



Auto Clamping Adjustment System “Active-ACAS”

  • Patented key technology for excellent loss performance

  • Clamp pressure can be automatically optimized and fiber offset is corrected



High Environmental Durability

  • IPx2 water resistance

  • IP5x dust resistance

  • Splice at 50°C

  • Work at 3660m

  • 76cm drop on 5 faces



Brand-new touch panel and UI

  • Wide and high resolution touch panel -5" touch screen colour LCD display

  • Smartphone-like easy operation



Wireless LAN connectivity to SumiCloud™

  • SumiCloud™ smartphone App. to support splicing job

  • WLSD card brings SumiCloud™ services to your splicer via our smartphone App.



Video Tutorial

  • Video tutorial to help splicing job

  • SumiCloud™ App. to watch tutorial video on smartphone


Ribbon fiber splicer, Mass fusion splicer for up to 12 fiber ribbon Industry only dual independent heaters and Auto Clamping Adjustment System "ACAS"



Fiber Cleavers


FC-6R series

FC-6R series is the flagship model in bench top cleaver product range.

"R" stands for "Rotating" and as its name shows,

FC-6R series has rotating blade. Applying

rotating blade, a blade adjustment will not

be required until the end of blade life.


FC-6 series

FC-6 series is a traditional bench top cleaver,

simple and easy to use. It is available with,

or without, a fibre offcut collector.

FC-6(S or M)-C which has offcut collector is also available.


FC-8R series

FC-8R-FC is a handheld cleaver with the auto-rotating blade, smart cleave counter, and offcut collector, for up to 12 fiber ribbon.
Upgrade version of FC-7R, the industry's first automatic blade rotation cleaver.
Always ensures high precision cleaves.



  • Smart cleave counter

  • Half-open
    Suitable when using in one hand

  • Wide-open
    Suitable when using on the workbench or during the maintenance

  • User-selectable blade operation Rotation and fixed mode are available

2

SumiCloud™

Enhance your fibre optic splicing experience



Description

SumiCloud™ is a powerful tool that supports your fusion splicer in the field.

Using your smartphone, your splicer connects to the internet and Sumitomo's cloud services which include data management, asset management, firmware updates and maintenance support.

Enjoy a new generation splicer experience with SumiCloud™.



Splice Data Management



Real time data sharing on your smartphone and web browser

Remote Screen Capture



  • Capturing real-time splicer display for better support



Help Videos



  • Wide range of help videos to support user training and proactive maintenance



The other useful functions will be released soon



  • Report Builder

  • Finish up your field report by several taps on your smartphone

  • Auto Diagnosis

  • Remote health check to minimize troubles in the field

  • Splicer's Firmware Update

  • Keep your splicer firmware up-to-date with the latest version to ensure optimum performance

  • Remote Lock

  • Lock and unlock your splicer for safety and security

Other Accessories


Jacket remover

JR-M03

The JR-M03 is designed to remove 250um & 900um fibre coatings and up to 3mm jacketing insulation.

JR-6+

Adjustable temperature

Water protected to IPx1 and shock-resistant

Built-in battery charger

Easy maintenance and field replaceable blade


Fibre holder

FH series

The fibre Holders, FH series are designed to work with Sumitomo Electric fusion splicers and help load optical fibre correctly in the splicers. The fibre Holders are supplied in pair for the left and right.



FCC-15



Fibre coating clamp FCC-15 is used ETK1724131 Sep. 25, 2017 exclusively with Sumitomo fusion splicers.

FCC-15 is pre-fitted in the Active clad alignment fusion splicer, T-400S

3

BU-16

The detachable battery pack, BU-16 is specifically designed for Sumitomo Electric fusion splicers, TYPE-72, TYPE-82 and TYPE-Q102 series


BU-11

The detachable battery packs, BU-11 series are specifically designed for Sumitomo Electric fusion splicers, TYPE-71, 81, Q101 series, T-55, T-600C and Z1C.


BU-15

The Built-in Battery Pack, BU-15 is specifically designed for Sumitomo Electric Fusion Splicer, T-400S.


BU-12

The Detachable Battery Packs, BU-12 series are specifically designed for Sumitomo Electric Fusion Splicers, TYPE-100S/Se, 201/201e and QH201e series.


BC-12

Dual position battery charger for BU-12S and BU-12L.


BC-16

Battery charger for BU-16 and BU-11 series.

Charge Sumitomo Electric batteries outside the splicer body

Compact and light weight


Lynx-CustomFit™ Splice-On Connectors

Fusion spliced SC, LC, ST, FC and MPO field installable fiber optic connectors.

Features

Adapting splicing technology, Lynx-CustomFit™ Splice-On Connectors provides a highly reliable optical connector on site.

Optimize the cable length as exact length, Lynx-CustomFit™ Splice-On Connectors solve cable snarl, slack in the floor, trays, and racks, moreover, contribute to improving air-conditioning efficiency.
